KW Coilover Kit, BMW E46 M3

KW V1

Sporty and Balanced with KW factory pre-set dampening

The ideal system for customers who like to choose the customer lowering of their vehicles while counting on the extensive driving tests of our experienced engineers who have preset the dampers for the ultimate balance between sporty driving, comfort and safety.

KW V2

Sporty and personalized with adjustable rebound dampening

This system is designed for the driver who requires not only determining the individual lowering of their vehicle, but having the ability to adjust the damper settings to fine tune the system to their needs.

Adjustable rebound damper allows adjustment of the pitch and roll of the vehicle adapting it to one's own driving preferences.

KW V3

Race technology for the road, with adjustable compression and rebound dampening

State of the art motorsport technology enables better performance on the streets.

Independently adjustable compression and rebound dampening allows for custom driving setups.

Exclusive KW patented system has dual level valves that allow for adjustment of the rebound dampening for your road comfort and the compression dampening that controls the driving dynamics.

KW V3 Clubsport

2 Way damping adjustable Coilovers for Race track and road

These set ups were specifically designed for the Nordschleife using track day tires. By using the optional adjustable top mounts, suspension geometry can be adjusted to the requirements of the tires and the intended use.

These adjustable top mounts coupled with the independently adjustable rebound and compression dampening technology individual set up adjustments according to vehicle load, tire characteristics and different track conditions. KW V3 Clubsports meets all needs for the road and the race track guaranteeing excellent handling, best performance, great agility and fantastic lap times.

The rebound adjuster knob provides 16 precise clicks to personally dial in your desired vehicle setup. Thus allowing you the possibility to influence wheel/tire loads or take into concern chassis characteristics.

Independent from rebound adjustment is the compression dampening, 12 precise adjustment clicks are provided to adjust the low-speed dampening. Most notably used to dial in wheel/tire setup.

These adjustment features allow the user to dial in vehicle weight, wheel/tire combinations, various road surfaces and environmental conditions.

- Independently adjustable rebound and compression damping technology
- Stainless steel technology "inox-line"
- Seamlessly adjusable lowering
- TÜV-tested adjustment range
- High-quality components for a long-term durability
- Adjustable rebound damping with 16 precise clicks
- Adjustable compression damping with 12 precise clicks
- Unique independent damping force adjustment
- Optional spherical bearing aluminum top mounts

KW V4 Clubsport

3-way damping adjustable coilovers; the technology of the 24-hour race winner

Using the Nordschleife as it's testing grounds and the 7-post rig, KW developed its KW V3 Clubsport coilover kit. Wheel loads, vehicle weight and chassis reinforcements (for increased body stiffness) can all be taken into consideration with adjustment capabilities of the KW V4 Clubsport.

Similar to KW V4 Racing 3-way damping adjustable coilovers, low-speed and high-speed compression adjustment is done via KW's patented two-valve control on the valve manifold.

By hand, you can tune the low-speed compression damping with six precise clicks on the purple adjustment dial. The gold adjustment dial allows the user to change the high-speed compression damping with 14 precise clicks.

Rebound adjustment is provided with 16 clicks, each providing a noticeable change. A reduction in rebound forces provides a more comfortable ride quality suitable for highway driving.

- 16 precise clicks in rebound adjustment dampening
- Adjustable compression damping with 6 clicks in low-speed range and 14 precise clicks in the high-speed range
- Seamlessly ajdustable lowering
- TÜV-tested adjustment range
- High-quality components for long-term durability
- Independent damping force adjustability with aluminum spherical bearing top mounts available
